MAP Technology Using Luminex 100 IS 2.3 Software
PN 89-00002-00-071 Rev. C 5 - 87
Maintenance Report - provides a history of all maintenance
operations performed during the date range entered by the operator.
Batch Summary Report - prints batch information in a sample
versus test grid format; useful for an assay developer to quickly
reference a test result for a particular sample.
Calibration Trend Report - provides information about all
instrument calibration operations that occurred during the date range
entered by the operator.
System Control Trend Report - provides information about all
verification operations that were performed during the date range
entered by the operator.
Data Analysis Report - displays all the information available in the
Data Analysis window. You access this report through the Analysis
Window. For more information on printing this report, see page 5-89.
‹
To print a report from a batch or a specific time frame:
Install the printer before initiating the print command.
1. Click Print Report. The Report Selection dialog box opens.
Figure 5-57. Report Selection Dialog Box
2. Select the type of report that you want to print and click Next.
For the Analyte, Clinical Patient, and Batch Summary Reports,
the Batch Selection dialog box opens. Select the batch to print.
See Figure 5-58. For the Quality Control, Maintenance,
Calibration Trend, and System Control Trend Reports, a dialog
box related to the specific report opens. The system information
may vary depending on the type of report you select.
