command. However, the sanitize command uses 10% to 20%
household bleach to decontaminate sample lines and the cuvette after
biohazard contact.
Save and Load
If selected, displays the run batch tab immediately after you set up
batch information and click Finish.
Save Only
Allows you to save the batch information. User can open the batch
later to acquire data.
Self Diagnostics
Performs a self-diagnostics to see if the Luminex analyzer and all
system operations are functioning correctly. Self-Diagnostics tests
these functions:
• Flash memory test
• Microcontroller RAM test
• Nonvolatile memory test
• DSP program CRC test
• DSP capture test
• High voltage module
• Channel backgrounds test
• Pressurization test
• Actuator test
• Syringe pump test
• Backflush valve test
• Debubbler valve test
Show Bead
After selecting an entry from the drop-down list, sets the histogram
to show events for only one beadset [bead set number],
events within the gate, or events inside and outside the gate.
Select (default) before setting the gate.
Single Step
Selecting this option on the toolbar pauses the system in between
each command or sample acquisition within a batch.
Skip [wells]
Enables you to deliberately bypass specific wells during batch
acquisition.
Soak
Prevents salt crystals from forming in the probe due to air exposure.
Soaking the probe replaces sheath fluid in the probe with water. You
should perform the soak function at the end of each day. The system
uses at least 250
µ L of distilled water.
