Luminex 100 IS Version 2.3 User Manual
Page 120
Luminex 100 IS User Manual Version 2.3
x
MAP Technology
5 - 78
PN 89-00002-00-072 Rev. C
3. Double-click anywhere within the graph to display the
Customization dialog box. See Figure 5-46. Notice across the
dialog box are five tabs: General, Axis, Font, Color, and Style.
Also notice that there are six buttons along the bottom of the
dialog box. They are the OK, Cancel, Apply, Original, Export,
and Maximize buttons.
Figure 5-46. Customization Dialog Box—General Tab
Customization Dialog Box Buttons:
OK: click to update the graph’s parameters with the new infor-
mation and exit the Customization dialog box.
Cancel: click to abort selections and exit.
Apply: Apply is similar to the OK button, but does not close the
Customization dialog box. It updates graph parameter with new
information.
Original: click this button to restore the edited information to
the previous or original values.
Export: click this button to export data from a Metafile or BMP
graphic to a .csv output file in the batch folder file, or to the clip-
board. You can also export to a printer and specify the object
size. Select the desired features and click Export. See Figure 5-
47.
