Print Data
Analysis Report
A printed batch report includes the following criteria that is applied
to the batch during analysis:
• batch name and test name
• formula used
• curve fit
• standards
• controls
• samples
• graph (this is the only way to print a graph of standards)
‹
To print data analysis reports:
1. On the Home tab, click Analysis.
2. In the Open Batch dialog box, select the desired batch to
analyze.
3. In the Analysis window, click Print Report. The Data
Interpretation Report displays a print preview. See Figure 5-61.
4. Select any print options along the title bar and then click the
print button (printer icon).
5. At the Microsoft Windows Print window, select your printer,
options, and click Print.
