Safety Information for Vertical Barrier Arm and Spikes
• Do not install the operator in such a way that the arm moves within 2 feet of a rigid object.
• Spike Warning. It is extremely important that the traffic spikes are clearly marked with a warning sign of potential hazard to
vehicles and the spike area is well illuminated.
• Speed limit through barrier area is 5 MPH. Install speed bumps, warning signs and hazard stripes where visible in the area
of the barrier gate, failure to do so may result in injury, damage to operator and vehicle.
• Users should be familiar with proper use of operator, these include; hardware operation, reversing functions and testing,
reversing loops, inherent reversing system, electric edges, photoelectric cells related external devices and possible hazards.
• Keep adults, children and objects away from operator and HAZARD ZONES.
• Pedestrians must be provided with a separate access.
• All electrical connections should be made in accordance with local electrical codes.
• Security features should be installed to avoid unauthorized use.
• Controls must be installed far enough away from the operator to avoid any contact when operating the controls but no
further away from the operator than 50 ft. If the installed hardware is in violation of these restrictions remove the operator
from service immediately and contact your service dealer.
• When manually operating the gate operator arm, the user MUST make sure that the gate area is clear BEFORE operating the
controls.
• When removing the operator lift the arm to the full open position and shut off power at the service panel.
• Operators and components should be properly installed and maintained following the recommended service schedule,
test the operator monthly. Keep all debris away from operator housing vents and off of arm. Contact your service dealer for
any maintenance or repairs.
• Vehicular operators can produce high levels of force, it is important that you are aware and eliminate possible HAZARDS;
Pinch Points, Entrapment Areas, Absence of Controlled Pedestrian Access, Traffic Backup.
Reduce the risk of injury or death,
read and follow all instructions.
Familiarize yourself with safety warnings, instructions, illustrations, and wiring guidelines to ensure that the
installation is performed in a safe and professional manner. Prior to installation check all local building codes
and ordinances to ensure compliance.
947GHT4
Important: Barrier gate operator CANNOT sense a person under
the raised arm.
This scenario is VERY DANGEROUS and MUST NEVER OCCUR!!
