4 ticket spitter entry lane, Dual channel, Speed bump ticket eject loop – Controlled Products Systems Group 1603-080 User Manual
Page 20: Down loop ticket spitter, 1 ft. minimum distance
1603-065-T-4-13
18
SW 1
1
ON
2
3
4
5
6
7
8
9409
Dual Channel
4.4 Ticket Spitter Entry Lane
REVERSE
SENSITIVITY
TIME
DELAY
POWER
1
ON
2
3
4
5
6
7
8
1
ON
2
3
4
5
6
7
8
NC NO
UP
LOOP
DOWN
LOOP
1 2 3 4 5
6
7 8 9 10 11 12 13
14
1601
SW 1, switch 4 is ON.
SW 1, switch 7 is OFF (Timer). The arm will rotate
down after the vehicle clears the down loop.
See note below.
Speed Bump
Ticket Eject
Loop
Com
NO
Com
NO
Down Loop
Ticket
Spitter
SW 1
SW 2
A
A
Note: The timer can be used with a down loop. When timer is ON with a
down loop, it will start countdown when the arm has fully raised.
Activation of the down loop will cancel timer countdown. Useful when
the ticket spitter has been activated but vehicle does not move forward
to activate the down loop. The arm will remain UP. Timer will time out
and lower the arm without the down loop being activated.
Helps increase distance
and time between vehicles.
Main Terminal
1 Ft. Minimum Distance
