5.1 Mounting Hub
5.2 Mounting Aluminum Arm
Locking
Plate
Bolt
Screw
Horizonta
l
Hub
V
ertical
SECTION 5 - ARM INSTALLATION
The 14 ft. aluminum arm mounts on the side of the operator opposite oncoming traffic (either straight or folding arm).
Note: To install folding aluminum arm,
refer to instruction sheet supplied in
aluminum folding arm kit. P/N 1601-310
Operator in the Down position.
Test hub UP and DOWN
position before installing arm.
14 Ft. Arm
Arm DOWN....
Spikes UP
Arm UP....
Spikes DOWN
