MCN Remote Comparator Display Appendix A
CTI Products, Inc. Changing Status Message Text
68-10856-210
91
[ALM-CTRL]
VOTE=L
DISABLE=L
; Sub-Category for alarms
00 00 1F 0F 0 06 00 0000 00000 0 00 " "
01 01 2F 70 0 06 00 0000 00000 0 00 "Active"
02 04 70 70 0 06 00 0000 00000 0 00 "Fail"
03 05 4F F0 1 06 00 0000 00000 0 00 "Access"
; Sub-Category for control
00 40 2F 70 0 04 00 0000 00000 0 00 " "
05 41 70 70 0 04 00 0000 00000 0 00 "On"
06 44 70 70 0 04 00 0000 00000 0 00 "Off"
07 50 E0 70 1 04 00 0000 00000 0 00 "Run"
08 51 E0 70 1 04 00 0000 00000 0 00 "Stop"
09 00 6E 70 1 04 00 0000 00000 0 00 "Err"
378 00 00
378 FE 01
378 FD 02
378 FB 04
378 F7 08
378 EF 10
378 DF 20
378 BF 40
378 7F 80
378 FE 00
378 FD 00
378 FB 00
378 F7 00
378 EF 00
378 DF 00
378 BF 00
378 7F 00
N72 P8 N72 P8 N72
N58 P8 N40
N61 P8 N61 P8 N61
Figure 38 - Sub-Category MCNRCD.CFG File
Figure 38 shows an example MCNRCD.CFG file that includes two categories,
one is DEFAULT and the other is ALM-CTRL.
