MCN Remote Comparator Display

Appendix D

CTI Products, Inc.

Modem Configurations

68-10856-210

108

12. Appendix D - Modem Configurations

UDS V.3225 MODEM CONFIGURATION SHEET

Configuration Procedure for V.3225 Modems version 2.12.12:
1. Load Factory Option Set #1.
2. Change the required settings for your operating mode except the Options Restored at

Disconnect. ( See * ) All options different than option set #1 are highlighted.

3. Save Settings.
4. If you are using a Dial-up mode Set Options Restored / Retained as needed.
5. If you are using leased line mode, connect both modems together over the

leased line or

test line and wait until the modems train and connect. Once the modems are on line set the
Options Retained / Restored as required.

6. Save Settings.

Menu Options 1

Leased Line Modem

Dial Up Line Modem

Modem Parameters

DCE Rate

9600 Trellis

Normal Originate / Forced
Answer
-HIB Modem
-PC Modem

Forced Answer

Normal Originate

Forced Answer

Normal Originate

V.32 Fast Train

Disabled

Auto Retrain

Enabled

Transmit Clock

Internal

Dial Line / Lease Line

Leased Line

Dial Line

4-Wire (Recommended)

TX Level is 0 dbm

Dial Backup is

LookBack Timer is 15

Jack Type

RJ11 (permissive)

Line Current Disconnect

Long

Long Space Disconnect

Disabled

V.32 Cleardown

Don’t Care

V.22 Guard Tone

Disabled

MNP Options

MNP Protocol

Enabled (\N3)

DTE Speed
-HIB Modem
-PC Modem

Constant DTE Speed
Constant DTE Speed

Auto Fall Back

Normal

Flow Control

RTS/CTS (\Q3)

XON/XOFF Pass Through

Don't Care

Data Compression

Enabled(%C1)

Inactivity Timer

Off

MNP Break Control

DTE Parameters

Async / Sync Data

Async

DTE RATE

19200 or 9600

19200

Char Size

8 Bit

Parity

Dial Method

Async Commanded Dialer
