MCN Remote Comparator Display Appendix D
CTI Products, Inc. Modem Configurations
68-10856-210
110
UDS V.3229 MODEM CONFIGURATION SHEET
Configuration Procedure:
1. Load Factory Option Set #1.
2. Change the required settings for your operating mode except the Options
Restored at Disconnect. ( See * ) All option set changes from option set #1 are
highlighted.
3. Save Settings.
4. If you are using a Dial-up mode Set Options Restored / Retained as needed.
5. If you are using leased line mode, connect both modems together over the
leased line or test line and wait until the modems train and connect. Once the
modems are on line set the Options Retained / Restored as required.
6. Save Settings.
Factory Options 1 Leased Line Modem Dial Up Line Modem
Modem Options Modem Options Modem Options
DCE Rate 14400 14400
Normal Originate
-HIB Modem
-PC Modem
Forced Answer
Normal Originate
Forced Answer
Normal Originate
Fast Train Disabled Disabled
Auto Retrain Enabled Enabled
Sq. Auto Rate Disabled Disabled
Transmit Clock Internal Internal
Dial Line TX level -10 dbm -10 dbm
Dial / Leased Line Leased Line Dial Line
4 Wire or 2 Wire
Leased TX Level 0dBm -
Manual Dial Backup
Loopback Timer 15 Min. -
Jack Type RJ-11 RJ-11
Line Current Disconnect Long Long
Long Space Disconnect Disabled Disabled
V.22 Guard Tone Disabled Disabled
Protocol Options
LAPM Protocol Disabled Disabled
MNP Protocol Enabled (\N7) Enabled (\N7)
Protocol Fallback Disabled Disabled
Data Compression Normal (%C1) Normal (%C1)
DTE Speed Constant DTE Speed Constant DTE Speed
DTE Flow Control RTS (\Q3) RTS (\Q3)
DCE Flow Control CTS (\Q3) CTS (\Q3)
XON/XOFF Passthru Don't Care Don't Care
Inactivity Timer Off Off
Break Option #5 #5
V.42 Fast Detect Enabled Enabled
