0.0 MAIN MENU
1 = Normal Operation
2 = Port Setup
3 = Display Setup
4 = Miscellaneous
2.0 PORT SETUP
1 = Analog Output
2 = Relays
3 = Comm Output
4 = Aux Input
3.0 DISPLAY SETUP
1 = Flow Setup
2 = Temperature Setup
3 = Totalizer Setup
4 = Sample Rate
4.0 MISCELLANEOUS
1 = Set Group
2 = Corrector Setup
3 = Password Setup
CH1: 5056.3 SCFM
CH2: 71.2 F
Σ = 435226 SCF
(grp1) (dd) (mode N) (m)
Normal Operation
QUICK
OPERATION
MENU
Menu Control
The prompt line displays appropriate key strokes for the required menu level. If a key is pressed that is not
valid for that menu, Invalid Response will flash briefly across the prompt line. The key pad and key
assignments are shown below:
•
At any time, the HOME key can be pressed and the main menu will display. HOME can be used to escape
from most routines, or restart a progression into the menu structure.
When (N)ext is displayed on the prompt line, more than two menu selections are available. Press N to scroll
through all the selections.
The UP key, will back-out of a menu level. The menu moves back one level each time the UP key is pressed.
The UP key only functions when UP is displayed on the prompt line.
To make a selection, press the numeric key associated with the desired menu selection. The selection does
not have to be displayed, but it must be one of the available selections.
The quick operation menu is shown below:
Key Assignments
3.1.2 STD VOLUME
1=Cu feet
3=Liters
(CF)?
Menu Level
Title
Available Selections
Prompt Line
3=Cu meter
Current Selection
Display Characteristics
Key Pad
1 2 3 Y N
4 5 6 _ .
7 8 9 P
ENTR 0 # HOME UP
KEY KEY NAME ACTION
0-9 Numeric
Selects options and enters
numbers.
Y Yes Enter a yes response
N No or (N)ext
Enter a no response or
scroll to next screen
- Minus Enter a minus sign
Decimal Point Enter a decimal point
Back Space
Moves cursor back one space
P (P)revious Scrolls to the previous screen
ENTR Enter
Enters a numeric value or
response
HOME Home
Returns to the Main Menu or
escapes from routines
UP Up Move current menu up on level
