Technical maintenance
Create
d
by EBCCW
0
0
:06
Page 55 of 68 5478EN-3
.
Note! The shaft and sprocket are removed as one piece. These
can be replaced as one piece or as individual items. If replaced
as individual items make note of the orientation of the sprocket
wheel on the shaft.
• Re-fitting is the reverse procedure of the removal.
• After assembly the spiral elevator must be set up (section 5.3.2)
and then test run (section 5.6) to check that all items are
satisfactory.
• After approval the Spiral Elevator may be put into operation again.
