Mounting, installation, adjustment
Page 40 of 68 5478EN-3
3. Are any conveyor chain
plates moving unexpectedly
at any position throughout
the Spiral Elevator? This may occur if there are some loose
conveyor plates (see Section 6.3 on page 57). Yes / No
4. Are there any conveyor chain
plates which are raised at
any position? This may occur because conveyor plates are
loose or the reversing rollers or a sprocket
wheel are not aligned well (see Section 6.3 on
page 57). Yes / No
5. Are there any damaged
conveyor chain plates or is
there friction material
missing? If any are detected the conveyor chain plates
concerned are to be replaced (see Section
6.2.2 on page 48). Yes / No
6. Are conveyor chain plates
touching the frame, the
guide, the guard or anything
else? Adjust the guide or the guard and carefully
check the correct setting / dimension of this.
See 'technical specification', quotation or
drawing for any relevant settings. Yes / No
7. Do all products fit on the
conveyor chain? Check in the technical specification, quotation
or drawing whether the product dimensions are
correct to those specified. Yes / No
8. Do any products slide off of
the conveyor chain? Are the conditions, sizes and weights of the
products correct to the technical specification,
quotation or drawing?
Is there any 'foreign substance' on the product
or conveyor chain reducing the effect of the
friction material?
Generally the sliding of products should not
occur, therefore contact the supplier.
Yes / No
9. Are there any products that
do not continue over the
transfer on to or off of the
Spiral Elevator. Check the condition of the transfers.
Any transfers supplied as part of the system are
in addition to the standard Spiral Elevator and
generally these transfers are not powered,
therefore some product may remain on the
transfer (depending upon various factors such
as speeds, condition, size or weight of product).
Yes / No
10. Is the product arriving on to
and transferring off of the
Spiral Elevator correctly
oriented? The design of the adjoining equipment should
be checked. Yes / No
No. Check Remarks Passed
