Mounting, installation, adjustment
Page 36 of 68 5478EN-3
5.4.2 Checklist integration
After the integration the checklist given below should be completed to
ensure a satisfactory integration.
No. Component Remark Checked
1. Lower end Is the lower end at the correct height and is the distance to the
adjacent conveyor / machine satisfactory (should be below
25mm and suitable for other considerations regarding product
transfer and safety)?
For correct height refer to technical specification, quotation
details or drawings.
Yes / No
2. Upper end Is the upper end at the correct height and is the distance to the
adjacent conveyor / machine satisfactory (should be below
25mm and suitable for other considerations regarding product
transfer and safety)?
For correct height refer to technical specification, quotation
details or drawings.
Yes / No
3. Spiral Elevator Is there sufficient space around the Spiral Elevator to allow
adequate access for operation, and maintenance? Yes / No
4. Fastening /
foundation
Is the Spiral Elevator fixed to the floor satisfactorily and is the
central column vertical? Yes / No
