Mounting, installation, adjustment
Page 42 of 68 5478EN-3
Check (safety) provisions
The basic Spiral Elevator supplied by FlexLink does not include any
additional safety provisions such as isolators, stop/start devices,
emergency stopping systems or guards at the in-feed / out-feed ends.
Any issues with regard to the safety items should be investigated and
discussed with the designer of the control and safety system.
Below is a check list for some general safety items.
Should the (safety) provisions not function as expected, they should be set
or adjusted again or repaired by the person responsible
(installer / technician).
No. Check Remarks Passed
1. Does the stop button stop the
Spiral Elevator within the time
expected. Both the Spiral Elevator and the input/output
chain should stop immediately within the time
dictated in the 'technical specification',
control design specification or within 3
seconds depending upon speed. Yes / No
2. Does the Spiral Elevator stop
when the emergency stop is
pressed. The Spiral Elevator should stop immediately
and this should be less than 3 seconds
depending upon speed. Yes / No
3. Does the optional height / width
indicator function when
processing a product which is too
large. The height / width detector should react when
a product is coming by that is larger than the
specified product mentioned in the 'technical
specification' or quotation. Yes / No
