3.3 Working principle
The purpose of the Spiral Elevator is to transport products / goods vertically
to bridge a difference of height.
Figure 5 Principle sketch Spiral elevator
1 Conveyor chain
2 Upper end
3 Lower end
4 Return part
5 Gear motor (not shown)
1 2
3 4
5
