Technical specifications
Page 8 of 68 5478EN-3
2 Technical specifications
Below is the technical specification of the Spiral Elevator.
Further product details to which the Spiral Elevator has been designed are
contained within the overall Project Documentation (when purchased as
part of a Project System).
Use of the Spiral Elevator outside of the scope detailed within the technical
specification, quotation or documentation will invalidate the warranty.
General FlexLink Spiral Elevator specification
• 500 mm inclination per winding (9 degree)
• 3-8 windings
• 1000 mm nominal centreline diameter
• Speed 5 - 60 metres per minute
• Lower height:- 600, 700, 800, 900 or 1000 mm
- Adjustable -50/+70 mm
• Max load 10 Kg/m (specific Spiral Elevators may be with a lower
limit due to actual gear motor used)
• Product size:
- width= 50 - 200 mm
- length= 80 - 250 mm
- height= 1,5 x Length (max 300 mm)
- see Project Documentation if applicable
• Drive and idler ends are horizontal
• Chain width 100 mm
• Friction top chain
• Steel chain with bearings running on the inner guide rail
• Wet coated mild steel frame
• Column diameter 160 mm
• M8 thread for guide rail
