Object 6000h: Operating parameters
This object shall indicate the functions for code sequence, commissioning diagnostic control
and scaling function control.
Code sequence: The code sequence defines, whether increasing or decreasing position values are output,
in case the encoder shaft rotates clockwise or counter clockwise as seen from the point of view of the
shaft.
Scaling function control: With the scaling function the encoder numerical value is converted in software to
change the physical resolution of the encoder. The measuring units per revolution (object 6001h) and total
measuring range in measuring units (object 6002h) are the scaling parameters. The scaling function bit is
set in the operating parameters. If the scaling function bit is set to zero, the scaling function is disabled.
Bit structure for the operating parameters
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Use MS MS MS MS R R R R R R R R MD SFC CD CS
Table Description:
MS: Manufacturer Specific Function (not available)
R: Reserved for future use
MD: Measuring direction (not available)
SFC: Scaling function (0 = disable, 1 = enable)
CD: Commissioning diagnostic control (not availabe)
CS: Code sequence (0 = CW Up, 1 = CCW Up)
Code Sequence (CS Bit 0) is hardwired to Code Sequence (CS Bit 0) in object 2100h.
Subindex Description Data Type Default Value Access Restore after
BootUp
0h Operating Parameter Unsigned 16 1h rw yes
