Brickcom OSD-200 20xp - Manual (Page 68)

64
Select the item to turn off the audio transmission function.
B. Server Gain Setting
Set the audio input/output gain levels for sound amplification. The audio
gain values are adjustable from 1 to 6. The sound will be turned off if
the audio gain is set to
“Mute”.
C. Bit Rate
The available audio transmission bit rates include 16 kbps (G.726), 24
kbps (G.726), 32 kbps (G.726), 40 kbps (G.726), uLAW (G.711) and
ALAW (G.711). Both uLAW and ALAW signify 64 kbps but in different
compression formats. A higher bit rate means higher audio quality and
more bandwidth consumption.
D. Recording to Storage
Select from the drop-down menu to record the audio along
with the video into the SD card.
Click on to confirm the setting.
Chapter 9 - PTZ
Under the tab , there are categories including: , ,
, , , , ,
, , ,
Misc2>, and .
9.1 Preset
The Preset Programming can be found under this path: PTZ> Preset.
Totally 256 Preset Points can be programmed for the IP Camera. Please
refer to the instructions below to set a Preset Point.
A. Preset Setting
To setup a Preset Point, please first move the cursor to the live view
pane. Then left click and drag the red pointer with PTZ controls to a
