Chapter 8 - Streaming
Under the tab , there are categories including: Format>, , , Rate>, and . In Streaming, the Administrator can configure specific video resolution, video compression mode, video protocol, audio transmission mode, etc. Further details of these settings will be specified in the following sections. 8.1 Video Format (Video Resolution / Video Deinterlace) The Video Format setting can be found under this path: Streaming> Video Format. A. Video Resolution Under Video Resolution section, the available video resolution formats are including MJPEG and H.264. Up to 4 simultaneous channels can be configured. Click on to confirm the setting. B. Text Overlay Settings Users can select the items to display on the live video, including date, time and text. The maximum length of the text string is 20 alphanumeric characters. Click on to confirm the Text Overlay setting. C. Video Rotate Type Users can change video display type if necessary. Selectable video rotate types include Normal, Flip, Mirror, 90 degree clockwise, 180 degree rotate and 90 degree counterclockwise. The following is descriptions for different video rotate type. Flip If select , the image will be rotated vertically.
Format>, , , Rate>, and . In Streaming, the Administrator can configure specific video resolution, video compression mode, video protocol, audio transmission mode, etc. Further details of these settings will be specified in the following sections. 8.1 Video Format (Video Resolution / Video Deinterlace) The Video Format setting can be found under this path: Streaming> Video Format. A. Video Resolution Under Video Resolution section, the available video resolution formats are including MJPEG and H.264. Up to 4 simultaneous channels can be configured. Click on to confirm the setting. B. Text Overlay Settings Users can select the items to display on the live video, including date, time and text. The maximum length of the text string is 20 alphanumeric characters. Click on to confirm the Text Overlay setting. C. Video Rotate Type Users can change video display type if necessary. Selectable video rotate types include Normal, Flip, Mirror, 90 degree clockwise, 180 degree rotate and 90 degree counterclockwise. The following is descriptions for different video rotate type. Flip If select , the image will be rotated vertically.
Rate>, and .
In Streaming, the Administrator can configure specific video resolution,
video compression mode, video protocol, audio transmission mode, etc.
Further details of these settings will be specified in the following sections.
8.1 Video Format (Video Resolution / Video
Deinterlace)
The Video Format setting can be found under this path: Streaming> Video
Format.
A. Video Resolution
Under Video Resolution section, the available video resolution formats
are including MJPEG and H.264. Up to 4 simultaneous channels can
be configured.
Click on to confirm the setting.
B. Text Overlay Settings
Users can select the items to display on the live video, including date,
time and text. The maximum length of the text string is 20 alphanumeric
characters.
Click on to confirm the Text Overlay setting.
C. Video Rotate Type
Users can change video display type if necessary. Selectable video
rotate types include Normal, Flip, Mirror, 90 degree clockwise, 180
degree rotate and 90 degree counterclockwise.
The following is descriptions for different video rotate type.
Flip
If select , the image will be rotated vertically.
