45
 Record Stream to SD Card
Select the item and the alarm-triggered recording will be saved
into the Micro SD card.
Pre-trigger buffer recording function allows users to check what
happened to cause the trigger. The pre-trigger buffer time range
is from 1 to 3 seconds. Select to set the
recording duration after alarm is triggered. The setting range is
from 1 to 99999 seconds. Select
active> to record the triggered video until the trigger is off.
NOTE- Please make sure the local recording (with Micro SD /
SDHC card) is activated so that this function can be implemented.
Refer to Recording for further details.
c. File Name
Enter a file name in the File name field, ex. image.jpg. The uploaded
image ’s file name format can be set in this section. Please select the
one that meets the requirements.
 Add date/time suffix
File name: imageYYMMDD_HHNNSS_XX.jpg
Y: Year, M: Month, D: Day
H: Hour, N: Minute, S: Second
X: Sequence Number
 Add sequence number suffix (no maximum value)
File name: imageXXXXXXX.jpg
X: Sequence Number
 Add sequence number suffix (limited value)
File Name: imageXX.jpg
X: Sequence Number
The file name suffix will end at the number being set. For example,
if the setting is up to
“10,” the file name will start from 00, end at
10, and then start all over again.
