41
7.6 FTP
The FTP setting can be found under this path: System> FTP.
The Administrator can set as sending alarm message to a specific File
Transfer Protocol (FTP) site when an alarm is triggered. Users can assign
alarm message to up to two FTP sites. Enter the FTP details, which include
server, server port, user name, password and remote folder, in the fields.
Click on when finished.
7.7 HTTP
The HTTP setting can be found under this path: System> HTTP.
An HTTP Notification server can listen for the event notification messages
from the IP Cameras. Enter the HTTP details, which includes server name
(for instance, http://192.168.0.1/admin.php), user name, and password in the
fields. triggered and notifications can be sent to
the specified HTTP server.
Click on when finished.
NOTE- Please refer to: Application> Send HTTP notification / Motion
Detection for HTTP Notification settings.
7.8 Application (Alarm Settings)
The Application setting can be found under this path: System> Application.
The Camera equips four alarm inputs and two relay outputs for cooperating
with alarm system to catch events’ images.
A. Alarm Pin Selection
Select an alarm pin which is to be configured from the
Selection> field. Then click on the button below the field to carry
on alarm programming.
