62
B. H.264-1 / H.264-2 / H.264-3 / H.264-4 bit rate
The default setting of H.264-1 is 4096 kbit/s, and for H.264-2 / H.264-3 /
H.264-4 is 1024 kbit/s; the setting range for H.264-1 is from 64 to 8192
kbps, and for H.264-2 / H.264-3 / H.264-4 is from 64 to 2048 kbit/s.
C. Display Compression Information
Users can decide whether to display the compression information on
the home page.
D. CBR Mode Setting
The CBR (Constant Bit Rate) mode could be the preferred bit rate
mode if the available bandwidth is limited. It is important to take the
image quality into account while choosing the CBR mode.
Click on to confirm the setting.
8.3 Video OCX Protocol
The Video OCX Protocol setting can be found under this path: Streaming>
Video OCX Protocol.
In the Video OCX protocol setting page, users can select RTP over UDP,
RTP over RTSP(TCP), RTSP over HTTP, or MJPEG over HTTP, for
streaming the media over the network. In the case of multicast networking,
users can select the Multicast mode. Click on to confirm the setting.
Video OCX protocol setting options include:
A. RTP over UDP / RTP over RTSP(TCP) / RTSP over HTTP / MJPEG
over HTTP
B. Multicast Mode
Fill in all the blanks, including ,
H.264-1 / H.264-2 / H.264-3 / H.264-4 Video Port>,
Video Port>, and .
8.4 Video Frame Rate
