75
In the Camera - Misc2 (Miscellaneous) Setup Menu, users can setup
various functions such as Wide Dynamic Range (WDR), Auto Calibration,
2D Noise Reduction (2DNR), and TV System.
A. WDR
The WDR function is especially effective in environment with extreme
contrast. Click on button to save the setting.
B. Auto Calibration
With the Auto Calibration function, the IP Camera calibrates when the
deviation of dome pivot is detected. Click on button to save the
setting.
C. 2DNR
With the 2D Noise Reduction function, the processor analyzes pixel by
pixel and frame by frame to eliminate the environmental noise signal so
that the highest quality image can be produced even in the low light
conditions. Click on button to save the setting.
D. OSD
Select on OSD Setting to turn on the OSD display on the live
video. The OSD display shows the pan/tilt degree and the shooting
position of the Dome Camera, such as NE 050/00, which
“NE” indicates
the shooting position of the Dome Camera,
“050” indicates the pan
degree,
“00” indicates the tilt degree. Click on button to save the
setting.
E. Set Pan Zero
Click on to set the Dome Camera
’s currently shooting position to
be where the Dome Camera would start to pan (0 degree).
F. TV System
Select the video format that matches the present TV system. Click on
button to save the setting.
9.12 Camera - Default
The Default Setting can be found under this path: PTZ> Camera- Default.
