7.10 Network Failure Detection
The Network Failure Detection setting can be found under this path:
System> Network Failure Detection.
Network Failure Detection allows the IP Camera to ping another IP device
(e.g. NVR, VSS, Video Server, etc.) within the network periodically and
generates some actions in case of network failure occurs, for instance, a
Video Server is somehow disconnected.
Being capable of implementing local recording (through Micro SD card)
when network failure happens, the IP Camera could be a backup recording
device for the surveillance system.
A. Detection Switch
The default setting for the Detection Switch function is
the function by selecting
according to the schedule time that is previously set in the
setting page. Select
choose the desired schedule from the drop-down menu.
B. Detection Type
Input the IP device address and the period of ping time to ping. The
ping time setting range is from 1 to 99 minutes.
C. Triggered Action (Multi-option)
The Administrator can specify alarm actions that will take when network
failure is detected. All options are listed as follows:
D. Enable Alarm Output 1 /2
Select the item to enable alarm relay output.
E. Record Stream to SD Card
Select the item and the alarm-triggered recording will be saved into your
Micro SD card.
