Alpha Technologies Cordex CXPS-M 48_24-1200_600A - Manual (Page 60)

DRAWN: AZ/RW
QUOTE:
DATE:
CONFIG: SHEET:
4/5/2012
1 OF 1
TITLE:
CXPS-M-1200/600, 3T-CB,-48/+24V,2R,1C,2BATT
ISSUED: CHECKED:
DWG NO: A SIZE REV: APPROVED: TYPE: V1
Relay Rack: 0300047-002
7' x 23" (1000lb) Zone 4
0
5
15
10
20
25
30
35
40
7'
A
CXRF 48-4kW
Shelf: 030-801-20
Module: 010-623-20
RS 232
TM
CXC
Cordex STATUS
0540100-04
RS 232
STATUS
KYDEX REAR
COVER VENTED
0901000-751
CXRF 48-4kW
Shelf: 030-801-20
Module: 010-623-20
0200042-012
TPL Distribution Module
e/w large cable landings
6x 600A TPL Fuse
Positions and shunts.
RS 232
STATUS
0200042-036
TPL Distribution Module
e/w small cable landings
6x 600A TPL Fuse
Positions, shunts and
Controller
0200042-035
TPL Distribution Module
e/w large cable landings
6x 600A TPL Fuse
Positions and shunts.
RS 232
STATUS
G N B
MARATHON
M12V105FT
G N B
MARATHON
M12V105FT
G N B
MARATHON
M12V105FT
G N B
MARATHON
M12V105FT
BATTERY TRAY
0300061-001
CXDF 48-24V Shelf: 030-840-20
CXDF48-24/2kW Module: 012-527-20
cordex CXDF 48-24/2kW AC
DC AL M
cordex CXDF 48-24/2kW AC
DC AL M
cordex CXDF 48-24/2kW AC
DC AL M
cordex CXDF 48-24/2kW AC
DC AL M
CXDF 48-24/2kW
G N B
MARATHON
M12V105FT
G N B
MARATHON
M12V105FT
G N B
MARATHON
M12V105FT
G N B
MARATHON
M12V105FT
BATTERY TRAY
0300061-001
