Page 44
9400004-J0 Rev B
42
6.4 External Battery Return Bar Wiring (Optional)
Connect the external battery return bar(s) to the associated bay's battery return bus as shown in Figure 25.
NOTE:
The return side of TPL fuse holders must connect directly to the external return bus bar.
Figure 25 — Remote battery return bar wiring
External battery return bar
3x 750 MCM (reco-
mended for 1200A
applications)
CXPS-M power
system bay
