Figure 35 — insulation covers in place, Figure 36 — securing insulation covers to bay, Figure 35) – Alpha Technologies Cordex CXPS-M 48_24-1200_600A User Manual
Page 51
49
9400004-J0 Rev B
Figure 35 —
Insulation covers in place
Figure 36 —
Securing Insulation covers to bay
STEP 3
Secure the covers to the top of the bay with the plastic screws as shown in Figure 36.
STEP 2
Repeat on the right busbar and cables.
