DXP DVI, DXP DVI Pro, and DXP HDMI Series • SIS Configuration and Control

65

Command

ASCII Command

(Host to Switcher)

Response

(Switcher to Host)

Additional Description

Information Requests (continued)
Request part number

N

60-nnn[n]-01

]

Show the DXP part number:

DXP 44 DVI = 43-265-01

DXP 44 HDMI = 60-880-01

DXP 88 DVI = 43-266-01

DXP 48 HDMI = 60-1010-01

DXP 44 DVI Pro = 60-875-01

DXP 84 HDMI = 60-881-01

DXP 48 DVI Pro = 60-1009-01 DXP 88 HDMI = 60-882-01

DXP 84 DVI Pro = 60-876-01

DXP 88 DVI Pro = 60-877-01

Firmware Version Queries:

NOTE:

There are up to three separate sets of Extron firmware on which the switcher can report: the controller firmware,

which is the overall control firmware; the Ethernet protocol firmware, which handles the Ethernet interface; and
the latest optional Extron firmware update, which is available at

www.extron.com

.

Query controller firmware
version

Q

X2!]

View firmware version

X2!

to

the second decimal place.

Example:

Q

1.23

]

The factory-installed controller
firmware version is 1.23.

Query controller firmware
version (verbose)

0Q

X2!

X2@

X2@]

Provide a detailed status
of the Ethernet protocol
firmware, the controller
firmware, and any firmware
upgrade. The firmware that
is running is marked by
an asterisk (*). A caret (^)

indicates that the firmware has
a bad checksum or an invalid
load. ?.?? indicates that

firmware is not loaded.

Example:

0q

(See below.)

Ethernet
Protocol
Firmware

Response:

Description

DXP Firmware Version

Updated Firmware Version

* Indicates the Version Running

Upload Date and Time

3.03-1.13(1.81-DXP Series -Wed, 16 Jan 2003 00:00:00 GMT)-1.13*(1.81-DXP Series -Thu, 02 Sep 2011 18:42:05 GMT)

Request system status

S

X1^

X1^

X1&

X1*

X$]

Display voltages

X1^

, internal

temperature

X1&

, fan speed

X1*

(rpm), and power supply

status

X$

.

Example:

S

3.29•4.85•+077.80•03750•1

Power supply

is on and Ok.

Fan 1 rotating
at 3750 RPM

5 V Power System

at 4.85 V

3.3 V Power

System at 3.29

Internal

Temperature

NOTE:

X$

= Power supply status

0 = not OK, 1 = OK

X1^

= Voltage

Positive or negative voltage and magnitude of internal power supplies

X1&

= Temperature

Degrees Fahrenheit

X1*

= Fan speed

In RPM

X2!

= Firmware version number to second decimal place (n.nn)

X2@

= Verbose firmware version–description–upload date and time
