DXP DVI, DXP DVI Pro, and DXP HDMI Series • SIS Configuration and Control 55
X1^
= Voltage Positive or negative voltage and magnitude of power
supplies
X1& = Temperature Degrees Fahrenheit
X1* = Fan speed In RPM
X1( = EDID reference file for DDC 01 – 40 32 = 720p (default) data
EDID is a communications protocol or instruction set for the identification of display devices
to computers using the DDC (Display Data Channel) transmission standard. EDID information
consists of the resolution, refresh rate, and pixel clock information of a display device.
You can apply an EDID to a selected input by selecting one of the categories of EDID
files (see the
EDID table on the next page):
• The EDID of the display connected to an output (numbers 1 through the number of
outputs on your DXP)
• One of 28 factory-loaded EDID files (numbers 9 through 36)
• One of the four user-defined files, to which you have saved the EDID for the device
connected to output 1 (numbers 37 through 40)
X2) = EDID file data block 256 bytes of binary data
X2!
= Firmware version number Shown to second decimal place (n.nn)
X2@
= Verbose firmware version,
description, and upload date
and time
X2# = Sync present 0 = no sync
3 = signal present
X2$
= HDCP authorization status 0 = HDCP authorization off
1 = HDCP authorization on (default)
NOTE: If the source requires HDCP authentication, ensure that HDCP authorization
is set to On (the default).
