DXP DVI, DXP DVI Pro, and DXP HDMI Series • SIS Configuration and Control
63
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Names
Write global preset name
E
X&,X1#
NG
}
Nmg
X&,X1#]
Assign global preset
X&
the
name
X1#
.
Example:
E
1,Security1NG
}
Nmg01
,
Security1
]
Name global preset 1
Security1.
Read global preset name
E
X&
NG
}
X1#]
View the name assigned to
global preset number
X&
.
Example:
E
2NG
}
Security2
]
Write room name
E
X^,X1#
NR
}
Nmr
X^,X1#]
Assign room preset
X^
the
name
X1#
.
Example:
E
1
,
Classrm1NR
}
Nmr01
,
Classrm1
]
Name room 1 Classrm1.
Read room name
E
X^
NR
}
X1#]
Write room preset name
E
X^
*
X*,X1#
NP
}
Nmp
X^
*
X*,X1#]
Example:
E
1*3
,
Podium_DVDNP
}
Nmp01*3
,
Podium_DVD
]
Name room 1, preset 3
Podium_DVD.
Read room preset name
E
X^,X*
NP
}
X1#]
NOTES:
•
Do not use leading spaces in preset names.
•
If a preset is unassigned,
X1#
is [unassigned].
•
If a global preset is saved, but not yet named, the default name is Preset
X&
.
•
If a room preset is saved, but not yet named, the default name is Rm
X^
Prst
X*
.
Write input name
E
X!,X1#
NI
}
Nmi
X!,X1#]
Assign name
X1#
to Input
X!
.
Example:
E
1
,
PodiumCamNI
}
Nmi1
,
PodiumCam
]
Name Input 1 PodiumCam.
Read input name
E
X!
NI
}
X1#]
View the name of Input
X!
.
Write output name
E
X#,X1#
NO
}
Nmo
X#,X1#]
Assign name
X1#
to
Output
X#
.
Example:
E
1,Main PJ1NO
}
Nmo1,MainPJ1
]
Name Output 1 MainPJ1.
Read output name
E
X#
NO
}
X1#]
View the name of Output
X#
.
Lock (Executive) Modes
NOTE:
See “
Locking and Unlocking the Front Panel (Executive Modes)
39 for more information on the
lock modes.
Lock all front panel functions
1X
Exe1
]
Enable lock mode 1.
Lock advanced front panel
functions
2X
Exe2
]
Enable lock mode 2.
Unlock all front panel functions
0X
Exe0
]
Enable lock mode 0.
View lock status
X
X$]
NOTE:
X!
= Input number
1 – maximum number of inputs for your model
X#
= Output number
1 – maximum number of outputs for your model
X$
= Current front panel lock mode
0 = unlocked, 1 = all front panel functions locked,
2 = basic functions unlocked
X^
= Room number (for room presets)
Each room can have up to 10 room presets (
X*
) assigned.
X&
= Global preset number
00 – 32. 00 = current configuration
X*
= Room preset number
00 – current ties for the room in view mode, 10 maximum
X1#
= Name
Name of preset, room, input, or output
•
12 characters maximum for input, output, and global preset names
•
11 characters maximum for room names
•
Upper- and lowercase alphanumeric characters are valid.
