DXP DVI, DXP DVI Pro, and DXP HDMI Series • SIS Configuration and Control

58

Command

ASCII Command

(Host to Switcher)

Response

(Switcher to Host)

Additional Description

Mute Commands
Video mute

X#

*1B

Vmt

X#

*1

]

Mute Output

X#

video (video

off).

Video unmute

X#

*0B

Vmt

X#

*0

]

Unmute Output

X#

video

(video on).

View individual video mute

X#

B

X$]

View mute status

X$

for video

Output

X#

.

Global video mute

1*B

Vmt1

]

Mute all video outputs.

Global video unmute

0*B

Vmt0

]

Unmute video for all outputs.

Audio mute

X#

*1Z

Amt

X#

*1

]

Mute audio for Output

X#

(audio off).

Audio unmute

X#

*0Z

Amt

X#

*0

]

Unmute audio for Output

X#

(audio on).

View individual audio mute

X#

Z

X$]

View audio mute status

X$

for

Output

X#

.

Global audio mute

1*Z

Amt1

]

Mute audio for all outputs.

Global audio unmute

0*Z

Amt0

]

Unmute all audio outputs.

View output mutes

E

VM

}

X(

X(

...

X(

n

]

In verbose mode 2
or 3:
Mut

X(

X(

...

X(

n

]

Each

X(

response is the mute

status of an output, starting
from Output 1.
n = the maximum number of

outputs for this model.

Example:
DXP DVI Pro 88

E

VM

}

Mut01002300

]

Output 2 video, Output 5
audio, and Output 6 video
and audio are muted. All other
outputs are unmuted.

NOTE:

The

Mut portion of the response appears only when the switcher is in verbose mode 2 or 3 (see the

Set

verbose mode command

on page

70).

Save, Recall, and Directly Write Global and Room Presets

NOTES:

If you try to recall a preset that is not saved, the matrix switcher responds with the error code E11.

If the room is nonexistent, the matrix switcher responds with the error code E21.

The following characters are invalid or not recommended in preset names:

+ ~ , ` @ = [ ] { } < > ‘ ’ “ ” ; : | \ ? and {space}

Save current configuration as
a global preset

X&,

Spr

X&]

Save the current configuration
as preset

X&

. The command

character is a comma.

Example:

9

,

Spr09

]

Save current ties as preset 9.

Recall a global preset

X&.

Rpr

X&]

Recall global preset

X&

. The

command character is a
period.

Example:

5

.

Rpr05

]

Recall preset 5, which
becomes the current
configuration.

NOTE:

X#

= Output number

1 – maximum number of outputs for your model

X$

= Mute status for individual output

0 = unmuted, 1 = muted

X&

= Global preset number

00 – 32. 00 = current configuration

X(

= Audio and video mute status for

For each output:

all outputs (VM command)

0 = no signals muted, 1 = video only muted, 2 = audio only muted,

3 = video and audio both muted
