DXP DVI, DXP DVI Pro, and DXP HDMI Series • Operation

14

Input and Output Buttons

Each DXP model has as many input buttons as output buttons, regardless of how
many inputs and outputs it actually has. On models with four inputs or outputs,
buttons 5 through 8 behave like buttons 1 through 4, selecting inputs or outputs 1
through 4. The following table summarizes the button functions.

Primary Functions

1

2

3

through

8

Action:

Select an input or output for the tie being created.

Indications:

Blinking: potential tie or untie
Lit: current tie
Amber: video and audio tie
Green: video only tie
Red: audio only tie

Secondary Functions

I/O Grouping

Action 1:

Input 1 and Output 1:
Select an I/O group

mode.

Action 2/
indication:

Assign an input or output to the selected group.
Lit: The input or output is assigned to the selected group.

Presets

Action/
indication:

Select a preset in preset mode.
Lit: A preset has already been saved to this location.
Blinking: The preset location is selected to be saved.

Mutes

Action/
indication:

Outputs: Press and hold to mute the video, audio, or video and audio output.
Outputs, blinking: The output is muted.

Background
illumination

Action:

Press input buttons 1 and 2 to toggle between
background illumination and unlit buttons.

a

Input buttons — The input buttons do the following:
Primary functions (

):

Select an input.

Identify the selected input.

Secondary functions (

):

Input 1 only: With the Output 1 button, place the switcher in I/O grouping mode
(see “

I/O Grouping

” on page

32).

Select a global preset (see “

Saving and Recalling Presets

” on page

29).

Inputs 1 and 2 only: Toggle button background illumination on and off (see

Setting the Button Background Illumination

” on page

44).

b

Output buttons — The output buttons do the following:
Primary functions (

):

Select outputs.

Identify the selected outputs.
