Technologic

®

Constant Speed Pump Controller Installation, Operation and Maintenance Manual

34

Parameter List

Variable

Description

Section

Default Value

Field Value

Node

The node number should be supplied by the BMS.

4.3.10.2

10

AI Ovrd

Select “Y” to override analog inputs through the

4.3.10.2

N

communications port. See section 4.3.10.5.

Enable

This must be set to “Y” to utilize RS-485 communications.

4.3.10.3

Y

Modbus

It should only be set to “N” to upload software upgrades.

Node

The node number should be supplied by the BMS.

4.3.10.3

10

AI Ovrd

Select “Y” to override analog inputs through the

4.3.10.3

N

communications port. See section 4.3.10.5.

Enable

This must be set to “Y” to enable Lonworks communications.

4.3.10.4

Y

Lonworks

AI Ovrd

Select “Y” to override analog inputs through the

4.3.10.4

N

communications port. See section 4.3.10.5.

Purge Time

Time, in minutes, that the pumps will run immediately after

4.3.11

10

starting the system in automatic mode, a value of 0 disables

purging.

Number of

Number of pumps that will turn on when purging is active.

4.3.11

1

Pumps (Purge)
App Type

The application type is required if staging will be based on

4.3.11

Cool

temperature.

DP Switch

Proof timer, in seconds, prior to setting a pump fail alarm after 4.5.1

10

Pr Tm

receiving a continuous high signal from a DP switch

Low Sys Press

The pressure, in PSI, below which an alarm or event will be set

4.5.2

½ System

Pressure

Low Sys

The proof timer, in seconds, prior to setting an alarm or event. 4.5.2

0

Pr Tm

A value of 0 disables this alarm or event.

Alarm

Set this value to “Y” to consider low system pressure an alarm, 4.5.2

N

(Low Sys Pr)

or set it to “N” to consider it an event.

Stop Pumps

Set this value to “Y” to stop all pumps in the event of a low

4.5.2

N

(Low Sys Press) system pressure alarm or event. Set it to “N” to continue

operation normally during this alarm or event.

High Sys

The pressure, in PSI, above which an alarm will be set

4.5.3

1.5 x System

Press

Pressure

High Sys

The proof timer, in seconds, prior to setting an alarm.

4.5.3

20

Pr Tm

A value of 0 disables this alarm.

Low Suct

The pressure, in PSI, below which an alarm or event will be

4.5.4

5

Press

set for the analog input method

Pr Tm (Low

The proof timer, in seconds, prior to setting an alarm or event. 4.5.4

20

Suct Press)

A value of 0 will disable this alarm. Used for analog input and

pressure switch methods.

Auto Reset

Select “Y” to allow this alarm or event to be automatically reset. 4.5.4

Y

(Low Suct

The analog input method resets using the “Reset Press”. The

Press)

pressure switch method resets on a low signal on the low

suction pressure switch digital input.

Reset Press

The pressure, in PSI, at which the controller will automatically 4.5.4

10

(Low Suct

reset when the suction pressure rises above it. Used for the

Press)

analog input method only.

Alarm (Low

Set this value to “Y” to consider low suction pressure an alarm, 4.5.4

N

Suct Press)

or set it to “N” to consider it an event. Used for analog input

and pressure switch methods.

High Suc Press The pressure, in PSI, above which an alarm or event will be set

4.5.5

System

Pressure

High Suc

The proof timer, in seconds, prior to setting an alarm or event. 4.5.5

0

Pr Tm

A value of 0 disables this alarm.
