Technologic ® Constant Speed Pump Controller Installation, Operation and Maintenance Manual 26
Setup Menu
4.5.8 Low Level
Path: Status Screens/Setup(3)/Alrm/Evt(5)/Low
Level(8)
Low Level
Low Level PT: ##s
OK? $ (Y/N)
See Table 37 for a description of the Low Level vari-
ables.
Variable Units Description Default Range Field
Value Value
Time Sec- The proof time prior 0 0-99
onds to setting a low level
alarm, see section
4.3.8 to set up the
low level digital input
Table 37: Low Level Variables
4.5.9 Volts Tolerance
Path: Status Screens / Setup (3) / Alrm/Evt (5) /
Volts Tolerance (9)
Volts Tolerance
Tolerance: ###%
Proof Time: ##s
OK? $
See Table 38 for a description of the Voltage vari-
ables.
Variable Units Description Default Range Field
Value Value
Toler- % This tolerance is 0 0-100
ance applied to the name-
plate voltage. A value
of 0 disables this
alarm.
Proof Sec- The proof timer prior 3 0-99
Time onds to setting a voltage
alarm.
Table 38: Voltage Variables
4.6 EZ-Start
Path: Status Screens / Setup (3) / EZ-Start (6)
EZ-Start will prompt the user for the parameters required to start up the system quickly. Some of these values will
already be correct due to the factory setup that is done for each Technologic
® Constant Speed Pump Controller. Use
PREV and NEXT to navigate through these screens while the cursor is on the OK field. Press NO and ENTER at the OK
prompt to edit the values, or press YES and ENTER to accept and exit EZ-Start.
EZ-START
→
Total # Pumps: #
OK?$
← EZ-START →
Pri Stg Mthd: (Meth)
Stage :###(U)
Destage:###(U) OK?$
← EZ-START →
Enter Nameplate Data
1:###.# 3:###.#
2:###.# OK?$
← EZ-START →
Enter Nameplate Data
4:###.# 6:###.#
5:###.# OK?$
←
EZ-START
No Flow Shutdown
Diff Temp:##F
Rstrt PSI:### OK?$
Pressure
Temperature
Diff Temp
For more than
3 pumps
Power
Amps
GPM
