Single Port KVM over IP
7 / 88
Please perform the following steps:
1. Power down your computer and IP-KVM switch
2. Connect the power supply to IP-KVM switch
3. Connect the monitor to the IP-KVM switch console side.
4. Connect the keyboard to the IP-KVM switch console side.
5. Connect the mouse to the IP-KVM switch console side.
6. Connect a VGA cable (15-pin HDDB Male / Male) with the Male side to both of the host
computer/KVM and the host port of the IP-KVM switch.
7. Connect one purple end of 3-in-1 cable to the PS/2 mouse port on the host
computer/KVM, and the other end of 3-in-1 cable to the host PS/2 mouse port on the
IP-KVM Switch.
8. Connect one green end of 3-in-1 cable to PS/2 keyboard port on the host
computer/KVM, and the other end of 3-in-1 cable to the host PS/2 keyboard port on the
IP-KVM switch.
9. (Optional) Connect the type A connector of USB A-B cable to the host computer, while
using remote mass storage control.
10. Connect Ethernet to LAN port and/or modem to serial port, depending on how you want
to access IP-KVM switch
11. (Optional) Connect serial power device to serial port for remote power control integrated
with Web user interface if IP-KVM switch
Note: Only one serial device like modem or serial power can be used simultaneously.
Initial IP configuration
In factory default, DHCP mode is disabled (IP auto configuration = None), and the IP
settings are as below:
IP address 192.168.1.22
Subnet mask 255.255.255.0
Default Gateway None
If DHCP mode is enabled (IP auto configuration = DHCP), the IP-KVM switch will try
to contact a DHCP server in the subnet to which it is physically connected. If a DHCP
server is found, it may provide a valid IP address, gateway address and net mask.
Before you connect the device to your local subnet, be sure to complete the
corresponding configuration of your DHCP server. It is recommended to configure a
fixed IP assignment to the MAC address of the IP-KVM switch. You can find the MAC
address labeled on the bottom side of the metal housing.
