C2G 52064 Single Port KVM over IP - Manual (Page 31)

Single Port KVM over IP
29 / 88
Return to the main page of the IP-KVM
switch .
Open the IP-KVM switch remote console.
Exit from the IP-KVM switch front end.
Table 5-2. Buttons from the front end
Warning
If there is no activity for 30 minutes, the IP-KVM switch will log you out,
automatically. A click on one of the links will bring you back to the login
screen.
5.2.2 Logout from the IP-KVM switch
This link logs out the current user and presents a new login screen. Please note
that an automatic logout will be performed in case there is no activity for 30
minutes.
5.3 The Remote Console
The Remote Console is the redirected screen, keyboard and mouse of the remote
host system that IP-KVM switch controls.
Figure 5-4. Remote Console
