Single Port KVM over IP
31 / 88
5.4.1 Remote Console Control Bar
The upper part of the Remote Console window contains a control bar. Using its
elements you can see the state of the Remote Console and adjust the local
Remote Console settings. A description for each control follows.
Figure 5-5. Remote Console Control Bar
Ctrl+Alt+Delete
Special button key to send the “Control Alt Delete” key combination to the
remote system (see also section 6.4.1 for defining new button keys).
Auto Adjust button
If the video display is of bad quality or distorted in some way, press this button
and wait a few seconds while the IP-KVM switch tries to detect the video mode
of VGA port to the controlled host and adjust itself for the best possible video
quality.
Sync mouse
Activates the mouse synchronization process. Choose this option in order to
synchronize the local with the remote mouse cursor. This is especially
necessary when using accelerated mouse settings on the host system. In
general, there is no need to change mouse settings on the host
.
Single/Double mouse mode
Switches between the Single Mouse Mode (where only the remote mouse
pointer is visible) and the Double Mouse Mode (where remote and local
mouse pointers are visible and need to be synchronized). Single mouse mode
is only available if using SUN JVM 1.4.2 or higher.
Options
To open the Options menu, click on the button “Options”.
