6.5.2 Keyboard/Mouse
Figure 6-22. Keyboard and Mouse Settings
Host Interface
Enables a certain interface the mouse is connected to. You can choose
between “Auto” for automatic detection, “USB” for an USB mouse, and “PS/2”
for a PS/2 mouse.
Warning
To use the USB and/or PS/2 interface you need a correct cabling
between the managed host and the managing device. If the managed
host has no USB keyboard support in the BIOS and you have
connected the USB cable only then you will have no remote keyboard
access during the boot process of the host. If USB and PS/2 are both
connected and you selected “Auto” as host interface, then the card will
select “USB” if available or otherwise falls back to “PS/2”.
To get USB remote keyboard access during the boot process of the host, the
following conditions must be fulfilled:
• the host BIOS must have USB keyboard support
• the USB cable must be connected or must be selected in the Host interface
option
PS/2 Keyboard Model
Enables a certain keyboard layout. You can choose between “Generic
101-Key PC” for a standard keyboard layout, “Generic 104-Key PC” for a
standard keyboard layout extendend by three additional windows keys,
