Appendix D - EGD Exchanges 44
Appendix D - EGD Exchanges
Exchange C1
Exchange C1 is described in “Appendix A - EGD, EtherNet/IP IO Format”.
Exchange P1
Exchange P1 is described in “Appendix A - EGD, EtherNet/IP IO Format”.
Exchange P2
G11/P11
Register Comm.
Index EGD Offset Read/Write
S05 5 0 R/W
S07 7 2 R/W
S08 8 4 R/W
S09 9 6 R/W
S10 10 8 R/W
S11 11 10 R/W
S12 12 12 R/W
- 14
14
M01 15 16 R
- 16
18 R
- 17 20 R
- 18 22 R
M05 19 24 R
M07 21 26 R
M08 22 28 R
M09 23 30 R
M10 24 32 R
M11 25 34 R
M12 26 36 R
M13 27 38 R
M15 29 40 R
M16 30 42 R
M17 31 44 R
M18 32 46 R
M19 33 48 R
M20 34 50 R
M21 35 52 R
- 36
54 R
