Appendix B - Drive Parameters 37
Data Format [19]: Amperage Value Decimal Data (Positive)
Min unit 0.01, inverter capacity 30HP or below
Min unit 0.1, for 40 HP and over
Example) If F11 (electronics thermal overload relay 1 level) 107.0 A (40 HP)
107.0 x 10 = 1070 =042E
H
If F11 (electronics thermal overload relay 1 level) 3.60A (1 HP)
3.60 x 100 = 360 =0168
H
Data Format [20]: Transmission Error Code
Field Description Code Description
1 FC (Function code) error 71 CRC error (no response)
2 Illegal address 72 Parity error (no response)
3 Illegal address (Data range error) 73 Other errors (no response)
- Framing error
- Overrun error
- Buffer full error
7 NAK
- Priority for comm.
- No privilege for writing error
- Forbidden writing error - -
Data Format [21]: Auto Tuning
(MSB) (LSB)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 0 REV FWD Data portion
0: Without forward rotation command
1: With forward rotation command
0: Without reverse rotation command
1: With reverse rotation command
Example) If P04 (Motor 1 auto tuning) = 1 : Forward rotation
0000 0001 0000 0001
B
= 0101
H
