Appendix B - Drive Parameters
29
M27
41 (29)
Frequency (Motor speed) setting at alarm final
2
- 42
(2A) -
-
- 43
(2B) -
-
- 44
(2C) -
-
M31
45 (2D)
Frequency setting at alarm final
5
M32
46 (2E)
Actual frequency at alarm
2
M33
47 (2F)
Actual value of torque at alarm
6
M34
48 (30)
Torque current at alarm
6
M35
49 (31)
Output frequency at alarm
5
M36
50 (32)
Motor output at alarm
5
M37
51 (33)
Output voltage (rms) at alarm
5
M38
52 (34)
Output voltage effective value at alatm
3
M39 53
(35)
Operation command at alarm
14
M40 54
(36)
Operation state at alarm
16
M41 55
(37)
General-purpose
output terminal at alarm
15
M42
56 (38)
Total operation time at alarm
1
M43
57 (39)
DC link voltage at alarm
1
M44
58 (3A)
Internal temperature of inverter at alarm
1
M45
59 (3B)
Temperature of cooling fin at alarm
1
M46
60 (3C)
Lifetime of main circuit capacitor
3
M47
61 (3D)
Lifetime of capacitor on PCB
1
M48
62 (3E)
Lifetime of cooling fan
1
- 63
(3F) -
-
- 64
(40) -
-
- 65
(41) -
-
- 66
(42) -
-
- 67
(43) -
-
- 68
(44) -
-
- 69
(45) -
-
F00
70 (46)
Data protection
1
F01
71 (47)
Frequency command 1
1
F02
72 (48)
Operation method
1
F03
73 (49)
Maximum frequency 1
1
F04
74 (4A)
Base frequency 1
1
F05
75 (4B)
Rated voltage 1
1
F06
76 (4C)
Maximum voltage 1
1
F07
77 (4D)
Acceleration time 1
12
F08
78 (4E)
Deceleration time 1
12
F09
79 (4F)
Torque boost 1
12
F10
80 (50)
Electronic Thermal 1 (Select)
3
F11
81 (51)
Electronic Thermal 1 (Level)
1
F12
82 (52)
Electronic Thermal 1 (Time constant)
16
F13
83 (53)
Electronic thermal overload relay (for DB resistor)
3
F14
84 (54)
Restart mode after momentary power failure
1
F15
85 (55)
Frequency limiter (High)
1
F16
86 (56)
Frequency limiter (Low)
1
F17
87 (57)
Gain (for freq set signal)
1
F18
88 (58)
Bias frequency
1
F20
89 (59)
DC brake (Starting freq.)
3
F21
90 (5A)
DC brake (Braking level)
1
F22
91 (5B)
DC brake (Braking time)
3
F23
92 (5C)
Starting frequency (Freq.)
3
F24
93 (5D)
Starting frequency (Holding time)
3
F25
94 (5E)
Stop frequency
1
