Applicable inverters – GE Industrial Solutions AF-300 P11_G11 Ethernet Interface User Manual
Page 10
About the OPC-G11S-ETN
4
Applicable Inverters
Item Description
Inverter type
AF-300G11/P11
Compatible inverter Model number
The two last digits of the model number should be B1 or later
Example: 6KG1123X1B1
Up to 22kW (30HP)
S08000
Minimum inverter ROM version
30 kW (40HP) and above
H08004
Note: This product can only be used for Inverters with ROM version numbers greater than or equal to the versions
shown above.
1. Check the ROM number of your Inverter as follows, using the inverter keypad.
2. Check that the Inverter Operation monitor (Operation mode) screen is displayed.
3. Press the [PRG] key of the Inverter once.
4. Select the "5. MAINTENANC" with the cursor and press the [FUNC/DATA] key.
5. Press the down cursor key to increment the display at the MAINTENANC screen. Finally, the ROM
number is shown in the maintenance information, as indicated by the display "INV=Hxxxxx or
Sxxxxx".
The maintenance and inspection items are similar to the Inverter unit, for detail refer to the Inverter
Instruction Manual.
