Appendix B - Drive Parameters
28
Appendix B - Drive Parameters
Parameter List
This table shows the mapping between Communication No. and drive parameter number. The
Communication No. is used when accessing parameters from the fieldbus.
G11/P11
Code
Communication
No. (Hex)
Description
Data
format
- 0
(0)
-
-
S01
1 (1)
Frequency command
2
- 2
(2)
-
-
-
3 (3)
-
-
-
4 (4)
-
-
S05
5 (5)
Frequency command
5
S06
6 (6)
Operation command
14
S07
7 (7)
Universal Do
15
S08
8 (8)
Accel Time F07
3
S09
9 (9)
Deccel Time F08
3
S10
10 (A)
Driving Torque Limit F40
5
S11
11 (B)
Braking Torque Limit F41
5
S12
12 (C)
Universal Ao
2
-
13 (D)
-
-
- 14
(E) -
-
M01
15 (F)
Frequency command (final)
2
- 16
(10) -
-
- 17
(11) -
-
- 18
(12) -
-
M05
19 (13)
Frequency command (final)
5
M06
20 (14)
Actual frequency
2
M07
21 (15)
Actual value of torque
6
M08
22 (16)
Torque current
6
M09
23 (17)
Output frequency
5
M10
24 (18)
Motor output
5
M11
25 (19)
Output current (rms)
5
M12
26 (1A)
Output voltage (rms)
3
M13
27 (1B)
Operation (final)
14
M14 28
(1C)
Operation state
16
M15
29 (1D)
General-purpose output terminal
15
M16
30 (1E)
Alarm content latest
10
M17
31 (1F)
Alarm content 1st previous
10
M18
32 (20)
Alarm content 2nd previous
10
M19
33 (21)
Alarm content 3rd previous
10
M20
34 (22)
Total operation time
1
M21
35 (23)
DC link voltage
1
- 36
(24) -
-
M23
37 (25)
Type code
17
M24
38 (26)
Capacity code
11
M25
39 (27)
ROM version
1
M26
40 (28)
Processing code in abnormal transmission
20
