Appendix B - Drive Parameters
31
C09
149 (95)
Multistep frequency setting (Freq. 5)
5
C10
150 (96)
Multistep frequency setting (Freq. 6)
5
C11
151 (97)
Multistep frequency setting (Freq. 7)
5
C20
152 (98)
JOG frequency
5
C30
153 (99)
Frequency command 2
1
C31
154 (9A)
Offset adjust (terminal [12])
4
C32
155 (9B)
Offset adjust (terminal [C1])
3
C33
156 (9C)
Analog setting signal filter
5
P01
157 (9D)
Number of motor 1 poles
1
P02
158 (9E)
Motor 1 (Capacity)
5
P03
159 (9F)
Motor 1 (Rated current)
19
P04
160 (A0)
Motor 1 (Tuning)
21
P05
161 (A1)
Motor 1 (On-line Tuning)
1
P06
162 (A2)
Motor 1 (No-load current)
19
P07
163 (A3)
Motor 1 (%R1 setting)
5
P08
164 (A4)
Motor 1 (%X setting)
5
P09
165 (A5)
Slip compensation control
5
H03
166 (A6)
Data initializing
1
H04
167 (A7)
Auto-reset (Times)
1
H05
168 (A8)
Auto-reset (Reset interval)
1
H06
169 (A9)
Fan stop operation
1
H07
170 (AA)
ACC/DEC pattern (select)
1
H08
171 (AB)
Rev. phase sequence lock
1
H09
172 (AC)
Start mode
1
H10
173 (AD)
Energy-saving operation
1
H11
174 (AE)
DEC mode
1
H12
175 (AF)
Instantaneous OC limiting
1
H13
176 (B0)
Auto-restart (restart time)
3
H14
177 (B1)
Auto-restart (freq. fall rate)
5
H15
178 (B2)
Auto-restart (holding DC voltage)
1
H16
179 (B3)
Auto-restart (OPR command self hold time)
3
H18
180 (B4)
Torque control
1
H19
181 (B5)
Active drive
1
H20
182 (B6)
PID control (Mode select)
1
H21
183 (B7)
PID control (Feedback signal)
1
H22
184 (B8)
PID control (P-gain)
5
H23
185 (B9)
PID control (I-gain)
3
H24
186 (BA)
PID control (D-gain)
1
H25
187 (BB)
PID control (Feedback filter)
5
H26
188 (BC)
PTC thermistor (Mode select)
1
H27
189 (BD)
PTC thermistor (Level)
5
H28
190 (BE)
Droop operation
4
H30
191 (BF)
Serial link (Function select)
1
H31
192 (C0)
Modbus-RTU (Address)
1
H32
193 (C1)
Modbus-RTU (Mode select on no response error)
1
H33
194 (C2)
Modbus-RTU (Timer)
3
H34
195 (C3)
Modbus-RTU (Baud rate)
1
H35
196 (C4)
Modbus-RTU (Data length)
1
H36
197 (C5)
Modbus-RTU (Parity check)
1
H37
198 (C6)
Modbus-RTU (Stop bits)
1
H38
199 (C7)
Modbus-RTU (No resp. error detection time)
1
H39
200 (C8)
Modbus-RTU (Response interval)
5
A01
201 (C9)
Maximum frequency 2
1
A02
202 (CA)
Base frequency 2
1
