Galaxy Pulsar Edge Power System Controller
Issue 3 October 2011
192
Table D-2: 48V Battery Related Items
Category Description Range Valve-Reg Flooded Li_ELiTE NiCd
Li-
LMP
obj,attr
Voltage Settings Rectifier Float Selective High Voltage
Shutdown
-50 to -60V 58.50 58.50 58.50 58.50 58.50 GM1,FSD
High Float Voltage Major Alarm -50 to -60V 57.00 57.00 57.00 57.00 57.00 HVA1,FTH
High Float Voltage Minor Alarm -50 to -60V 56.00 56.00 56.00 56.00 56.00 HFV1,FTH
Rectifier/System Float Voltage -42 to -56.5V 54.48 52.08 54.48 54.40 54.48 GM1,FSP
Battery on Discharge Float Alarm -46 to -55V 51.00 50.00 53.00 51.00 51.00 BDA1,FTH
Very Low Float Voltage Alarm -40 to -51V 46.00 46.00 46.00 46.00 46.00 VLA1,THR
Rectifier On Threshold -40 to -51V 44.00 44.00 44.00 44.00 44.00 DC1,ROT
Battery Disconnect
LV Battery Disconnect
1=Enabled
0=Disabled
1 1 0 1 0 CN1,ENA
LV Battery Disconnect Voltage -39.0 to -50V 42.00 42.00 42.00 42.00 42.00 CN1,DTH
LV Battery Reconnect Voltage -39.0 to -55V 48.00 48.00 48.00 48.00 48.00 CN1,RTH
Battery Disconnect Voltage or Disconnect
threshold Vmin in adaptive mode
39V to 50V
42.00 42.00 42.00 42.00 42.00 CN1,DTH
Disconnect threshold Vmax in adaptive
mode
39V to 50V
46.00 46.00 46.00 46.00 46.00 CN1,DVX
Imin in adaptive mode 0A to 9999A
3 3 3 3 3 CN1,DIN
Imax in adaptive mode 0A to 9999A 300 300 300 300 300
CN1,DIX
Batteries
Cells Per String 0 to 75 24 24 24 24 24 DC1,CPS
String End Of Discharge Voltage
-40.25 to -
48.75V
42.00 42.00 42.00 42.00 42.00 BR1,CEV
Recharge Current Limit Feature
1=Enabled
0=Disabled
1 0 0 0 1 BR1,CLE
Recharge Current Limit Value 5 to 1000A 50 50 25 25 25 BR1,CLT
Boost Maximum Duration 1 to 80 Hours 1 1 1 1 1 BS1,TMD
Voltage Imbalance Detect 1.5V to 3.0V 1.7 1.7 1.7 2.0 1.7 BR1,SCV
High Temperature Battery Disconnect 30 to 90 o C 75 75 75 75 75 BR1,TTH
High Battery Temperature 30 to 85 o C 55 55 55 55 85 BTHA1,THR
Very High Battery Temperature 30 to 85 o C 65 65 65 65 85 BTVH1,THR
Low Battery Temperature -40 to 10 o C -10 -10 -10 -10 -10 BTLA1,THR
Very Low Battery Temperature -40 to 10 o C -20 -20 -20 -20 -20 BTVL1,THR
Battery Slope
Compensation Slope Thermal Compensation (STC)
1=Enabled
0=Disabled
0 0 0 0 0 SC1,STT
High Temperature Voltage Step Down 45 to 85 o C 75 75 75 75 75 SC1,SPT
High Temperature Compensation Stop 30 to 55 o C 55 55 55 55 55 SC1,UTT
High Temperature Decrease Rate
1-10mV/ o C per
cell
3 3 3 3 3 SC1,USP
Nominal Temperature (No Temp Comp) 15 to 30 o C 25 25 25 25 25 SC1,NTT
Low Temperature Compensation Feature
1=Enabled
0=Disabled
0 0 0 0 0 SC1,RVE
Low Temperature Compensation Stop -5 to 20 o C 0 0 0 0 0 SC1,LTT
Low Temperature Decrease Rate
1-10mV/ o C per
cell
3 3 3 3 3 SC1,LSP
Probe Fail-Safe Enable
1=Enabled
0=Disabled
0 0 0 0 0 SC1,FSE
Battery Discharge Test
Timed Test Alarm Voltage Threshold -36 to -48V 44.00 44.00 46.00 44.00 44.00 BR1,TEV
Rectifier Voltage During Battery Test -42.00 to -52V 42.00 42.00 42.00 42.00 42.00 BR1,BTV
