Galaxy Pulsar Edge Power System Controller

Issue 3 October 2011

156

INP- Input Management

Related

Commands

obj,attr

Description

sta

cha

ope

type

Range of Values

"AUX1" – drives AUX1
alarm
"AUX2" – drives AUX2
alarm
“AUX3" – drives AUX3
alarm
“AUX4" – drives AUX4
alarm
“AUX5" – drives AUX5
alarm
“AUX6" – drives AUX6
alarm
"REMLVD" – Active signal

opens battery contactors
for built-in plant input,
or for LVD inputs, it
opens the contactor on
the card where the signal
is active.

inmnn,pol

Input alarming state



text

CLOSED, OPEN

where: m is the distribution interface module ID from 1 to 4

nn is the input number from 01 to the number of inputs supported by the distribution

interface module

Built-in plant inputs

Object

Signal Name

Default Description

In001

BALM1

Fuse Alarm Major

In002

BALM2

Open String

In003

BALM3

Auxiliary 1

In004

BALM4

Auxiliary 2

In005

BALM5

Auxiliary 3

In006

BALM6

Auxiliary Major Alarm

In007

ALM1

Emergency power off

In008

ALM2

PBT/TR

In009

ALM3

Emergency power off

In010

ALM4

Auxiliary 4

In011

ALM5

Auxiliary 5

In012

ALM6

Auxiliary 6

In013

ALM7

Auxiliary 7

In014

ALM8

Auxiliary 8

In015

ALM9

Auxiliary 9

COM- Call-Out Manager
