Galaxy Pulsar Edge Power System Controller
Issue 3 October 2011
186
Factory Default
Factory 24V
Rectifier Default
Factory 48V
Rectifier
Default
Category Description Range Factory Factory 24V Factory 48V obj,attr
ID1 Shunt Current Rating 0 to 9999 Amps 100 DCM01,SHA
ID2 Type
Battery/None
/Load
"NONE" DCM02,TYP
ID2 Shunt Current Rating 0 to 9999 Amps 100 DCM02,SHA
ID3 Type
Battery/None
/Load
"NONE" DCM03,TYP
ID3 Shunt Current Rating 0 to 9999 Amps 100 DCM03,SHA
ID4 Type
Battery/None
/Load
"NONE" DCM04,TYP
ID4 Shunt Current Rating 0 to 9999 Amps 100 DCM04,SHA
ID5 Type
Battery/None
/Load
"NONE" DCM05,TYP
ID5 Shunt Current Rating 0 to 9999 Amps 100 DCM05,SHA
ID6 Type
Battery/None
/Load
"NONE" DCM06,TYP
ID6 Shunt Current Rating 0 to 9999 Amps 100 DCM06,SHA
ID7 Type
Battery/None
/Load
"NONE" DCM07,TYP
ID7 Shunt Current Rating 0 to 9999 Amps 100 DCM07,SHA
ID8 Type
Battery/None
/Load
"NONE" DCM08,TYP
ID8 Shunt Current Rating 0 to 9999 Amps 100 DCM08,SHA
All Load Shunts Monitored
1=Enabled
0=Disabled
0 DC1,MLS
Built-in Inputs
Input 1 Description <=32 chars "Fuse Alarm Major" IN001,DES
Input 1 Type "FAJ1" IN001,TYP
Input 1 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN001,POL
Input 2 Description <=32 chars "Open String" IN002,DES
Input 2 Type "OSA" IN002,TYP
Input 2 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN002,POL
Input 3 Description <=32 chars "Auxiliary Major Alarm" IN003,DES
Input 3 Type "AMJ" IN003,TYP
Input 3 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN003,POL
Input 4 Description <=32 chars "Air Conditioner Fail" IN004,DES
Input 4 Type "AUX1" IN004,TYP
Input 4 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN004,POL
Input 5 Description <=32 chars "Door Open" IN005,DES
Input 5 Type "AUX2" IN005,TYP
Input 5 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN005,POL
Input 6 Description <=32 chars "SPD Fail" IN006,DES
Input 6 Type "AUX3" IN006,TYP
Input 6 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN006,POL
Input 7 Description <=32 chars "PBT/TR" IN007,DES
Input 7 Type "" IN007,TYP
Input 7 Active State
CLOSED=Closed
to RTN,
OPEN=Open to
RTN
"CLOSED" IN007,POL
Input 8 Description <=32 chars "High External Ambient" IN008,DES
