Galaxy Pulsar Edge Power System Controller
Issue 3 October 2011
188
Factory Default
Factory 24V
Rectifier Default
Factory 48V
Rectifier
Default
Category Description Range Factory Factory 24V Factory 48V obj,attr
Auxiliary Alarm 5 Front Panel Desc <=24 chars "Low Ext Ambient" AUX5,FDS
Auxiliary Alarm 6 Description <=32 chars "Fan Fail" AUX6,DES
Auxiliary Alarm 6 Front Panel Desc <=24 chars "Fan Fail" AUX6,FDS
Auxiliary Alarm 7 Description <=32 chars "Hydrogen Present" AUX7,DES
Auxiliary Alarm 7 Front Panel Desc <=24 chars "Hydrogen Present" AUX7,FDS
Auxiliary Alarm 8 Description <=32 chars "Customer Alarm 1" AUX8,DES
Auxiliary Alarm 8 Front Panel Desc <=24 chars "Customer Alarm 1" AUX8,FDS
Auxiliary Alarm 9 Description <=32 chars "Customer Alarm 2" AUX9,DES
Auxiliary Alarm 9 Front Panel Desc <=24 chars "Customer Alarm 2" AUX9,FDS
Auxiliary Alarm 10 Description <=32 chars "Customer Alarm 3" AUX10,DES
Auxiliary Alarm 10 Front Panel
Desc
<=24 chars "Customer Alarm 3" AUX10,FDS
Auxiliary Alarm 11 Description <=32 chars "Customer Alarm 4" AUX11,DES
Auxiliary Alarm 11 Front Panel
Desc
<=24 chars "Customer Alarm 4" AUX11,FDS
Auxiliary Alarm 12 Description <=32 chars "Customer Alarm 5" AUX12,DES
Auxiliary Alarm 12 Front Panel
Desc
<=24 chars "Customer Alarm 5" AUX12,FDS
Alarm Test
Alarm Test Enable
1=Enabled
0=Disabled
1 AT1,LTE
Duration of Each Relay Closure 5 to 300 sec 30 AT1,DUR
PMJ Relay Test Enable
1=Enabled
0=Disabled
1 AT1,PMJ
PMN Relay Test Enable
1=Enabled
0=Disabled
1 AT1,PMN
R1 Relay Test Enable
1=Enabled
0=Disabled
1 AT1,R1
R2 Relay Test Enable
1=Enabled
0=Disabled
1 AT1,R2
R3 Relay Test Enable
1=Enabled
0=Disabled
1 AT1,R3
Serial Communication
Ports Communication Port Type
LOCAL or
MODEM
"LOCAL" PS1,PTT
Local Port Write Access
1=Enabled
0=Disabled
1 LP1,WRE
Local RS-232 baud rate
2400/4800/ 9600/
Auto
"AUTO" LP1,BDR
Local RS-232 handshaking (Flow
Control)
No/SW/HW "NO" LP1,HSH
Number of Local RS-232 data bits 7,8 8 LP1,DBT
Local RS-232 parity n,e,o N LP1,PRY
Number of Local RS-232 stop bits 1,2 1 LP1,SBT
Local RS-232 Time-out 0-45 minutes 5 LP1,TMO
Local RS-232 Application
TERMINAL,
EVENT LOG
"TERMINAL" LP1,APP
Modem Port Write Access
1=Enabled
0=Disabled
1 MP1,WRE
Modem baud rate 2400/4800/ 9600 "2400" MP1,BDR
Number Of Modem data bits 7,8 8 MP1,DBT
Modem parity n,e,o N MP1,PRY
Number Of Modem stop bits 1,2 1 MP1,SBT
