Galaxy Pulsar Edge Power System Controller
Issue 3 October 2011
184
Factory Default
Factory 24V
Rectifier Default
Factory 48V
Rectifier
Default
Category Description Range Factory Factory 24V Factory 48V obj,attr
LV Load 2 Reconnect Voltage
19.5 to 27
-39.0 to -55.0V
22.00 44.00 CN3,RTH
LV Load 2 Reconnect Time Delay 0 to 300 sec 0 CN3,RDY
Load 2 Disconnect Description <=32 Chars "LVLD2" CN3,DES
Load 2 Disconnect Open
Description
<=32 Chars "LVLD2 Open" CNO3,DES
Load 2 Disconnect Open Front Panel
Description
<=32 Chars "LVLD2 Open" CNO3,FDS
Load 2 Disconnect Failed
Description
<=32 Chars "LVLD2 Failed" CNF3,DES
Load 2 Disconnect Failed Front
Panel Description
<=32 Chars "LVLD2 Failed" CNF3,FDS
Load Disconnect 3
Load 3 Disconnect
1=Enabled
0=Disabled
0 CN4,ENA
Load 3 Disconnect Control Mode
0=none,
1=voltage
2=voltage/time
1 CN4,DAM
Load 3 Disconnect Voltage
19.5 to 25V
-39.0 to -50V
21.00 42.00 CN4,DTH
Load 3 Disconnect Time Delay 0:0:0 to 4:59:59 0:00:00 CN4,DDY
Load 3 Reconnect Control Mode
0=none,
1=voltage
2=voltage/time
1 CN4,RAM
Load 3 Reconnect Voltage
19.5 to 27
-39.0 to -55.0V
22.00 44.00 CN4,RTH
Load 3 Reconnect Time Delay 0 to 300 sec 0 CN4,RDY
Load 3 Disconnect Description <=32 Chars "LVLD3" CN4,DES
Load 3 Disconnect Open
Description
<=32 Chars "LVLD3 Open" CNO4,DES
Load 3 Disconnect Open Front Panel
Description
<=32 Chars "LVLD3 Open" CNO4,FDS
Load 3 Disconnect Failed
Description
<=32 Chars "LVLD3 Failed" CNF4,DES
Load 3 Disconnect Failed Front
Panel Description
<=32 Chars "LVLD3 Failed" CNF4,FDS
Contactor Interfaces
Built-in Type
None/CN1/
CN2/CN3/CN4
"CN1" DCNC1,TYP
ID1 Type
None/CN1/
CN2/CN3/CN4
"CN1" DCN01,TYP
ID2 Type
None/CN1/
CN2/CN3/CN4
"CN2" DCN02,TYP
ID3 Type
None/CN1/
CN2/CN3/CN4
"CN3" DCN03,TYP
ID4 Type
None/CN1/
CN2/CN3/CN4
"CN4" DCN04,TYP
ID5 Type
None/CN1/
CN2/CN3/CN4
"None" DCN05,TYP
ID6 Type
None/CN1/
CN2/CN3/CN4
"None" DCN06,TYP
ID7 Type
None/CN1/
CN2/CN3/CN4
"None" DCN07,TYP
ID8 Type
None/CN1/
CN2/CN3/CN4
"None" DCN08,TYP
Imminent LVBD Shutdown
1=Enabled
0=Disabled
1 DC1,ISD
Imminent Shutdown Delay 2 to 120 seconds 15 DC1,ISY
Imminent LVBD Shutdown
1=Enabled
0=Disabled
1 DC1,ISD
Rectifiers
Rectifier Redundancy Loss Enable
1=Enabled
0=Disabled
0 GM1,RME
Rectifier Loadshare Enable
1=Enabled
0=Disabled
1 GM1,LSE
Rectifier Float Current Limit 30 to 100% 100 GM1,FCL
Rectifier Boost Current Limit 30 to 100% 100 GM1,BCL
